About the product
100W Enclosed Power Supply 15V/6.67A
Technical data
- Universal AC input 90 to 305Vac
- Built-in active PFC function
- Output voltage and constant current level can be adjusted through internal potentiometer
- IP65 for indoor and outdoor installations
- Operating altitude up to 5000 meters
- High reliable Driver with long lifetime
- Fully encapsulated Metal housing
- Suitable to use in a harsh environment with high dust density, humidity, vibration and altitude
- Working temperature range -55°C to +70°C
- Meet 6kV surge immunity level
- Withstand 10G vibration test
- Dimension 220 x 68 x 38.8mm (L x W x H)
- 6 Years Warranty
- Manufacturer MEAN WELL
Product specifications
| Output voltage (VDC) | 15 V |
| Manufacturer warranty | 6 years |
| Manufacturer | MEAN WELL |
| IP protection | IP65 |
| Application | ITE/AV |
| Voltage setting range | 13.5-17.0 VDC |
| Height | 38.8 mm |
| Width | 68 mm |
| Length | 220 mm |
| Protection class | Class I |
| Input voltage range (VAC) | 85-264 V |
| Power | 100 W |
| Efficiency | 92.00% |
