100W DC/DC-Converter, Input 18…75V, Output 12V/8.3A
Technical data
- 100W Isolated Output
- 4:1 Input Range
- Quarter Brick Package
- Efficiency 88%
- Regulated Output
- Protection: Input Under Voltage/Over Voltage/Over Current/Over Temperature
- Remote ON/OFF
- Dimension 36.8 x 57.9 x 12.7mm (L x W x H)
Product specifications
| Output voltage (VDC) | 12 V |
| Manufacturer | Cincon |
| Application | ITE/AV, Railway |
| Height | 12.7 mm |
| Width | 57.9 mm |
| Length | 36.8 mm |
| Package / case | Quarterbrick |
| Additional functions | Remote ON/OFF, Remote sense, Voltage Trim |
| Regulation | Regulated |
| I/O isolation | 1500 V DC |
| Input voltage ratio | N/A |
| Input voltage range (VDC) | 18-75 V |
| Nominal input voltage (VDC) | 24-72 V |
| Output current | 8300 mA |
| Power | 100 W |
| Manufacturer warranty | 3 years |
