About the product
Mini Cable Connector THB390 from Techno, Italy
Waterproof, Mini InLine Cable Connector with *wire protection for universal applications
- For cable diameter: Ø 7.0 – 13.5 mm
- Dimension: Ø 32.0 x 90.0 mm
- IP68
*Recommended for cable of cross-section < 1.0 mm2
Further, not published products and versions from Techno on request.
Technical data
No of connections: 2
No od poles: 3 (L-N-E)
Dimension:Ø 32.0 x 90.0 mm
Nominal Voltage: 450V AC
Nominal Current: 24A
Cable Cross sections: 0.25 – 2.5 mm2
For cable diameters: 7.0 -13.5 mm
Temperature: T 125°C
IP Rate: IP68
Housing material: PA66 GF UL94 V0 / PA66 UL94 V2 (Cable glands)
O-Rings: Silicone
Gasket: TPE
Material characteristics: Halogenfree
Errors and Technical changes reserved
Product specifications
| Pole | 3 |
| Nominal current | 24 A |
| Nominal voltage (V) | 450 V |
| Cable diameter | 7-13.5 mm |
| Wire section | 0.25-2.5 mm² |
| IP protection | IP68 |
| Certificates | CE, IEC |
| Manufacturer | Techno |
