About the product
3-pole T-Junction Connector TH402 from Techno, Italy
3way Junction Connector with screw connection
- 3-way T-Junction Connector
- For cable diameter: Ø 7.0 – 13.5 mm
- Dimensions: Ø 34.0 x 97.5 x 123.0 mm
- IP Rate: IP68
Further, not published products and versions from Techno on request.
Technical data
No of outlets: 3
Dimensions:Ø 34.0 x 97.5 x 123.0 mm
Nominal Voltage: 450V AC
Nominal Current: 32A
Cable cross sections: 0.5 – 4.0 mm2
For cable diameters: Ø 7.0 – 13.5 mm
Temperature range: T 125°C
Material:
– Housing: PA66 GF UL94 V0
– Cable distributor: PA66 GF UL94 V0
– Cable glands: PA66 UL94 V2
– O-Rings: Silicone
– Gaskets: TPE
Material characteristics: Halogenfree
Errors and Technical changes reserved
Product specifications
| Pole | 3 |
| Nominal current | 32 A |
| Nominal voltage (V) | 450 V |
| Cable diameter | 7-13.5 mm |
| Wire section | 0.5-4.0 mm² |
| IP protection | IP68 |
| Certificates | CE, IEC |
| Manufacturer | Techno |
