About the product
Set: InLine Cable Connector THR400 from Techno, Italy
Waterproof, InLine Cable Connector for universal applications
- For cable diameter: Ø 6.0 – 17.0 mm
- Dimension: Ø 34.0 x 140.0 mm
- IP68
Further, not published products and versions from Techno on request.
Technical data
No of connections: 2
No od poles: 5
Dimension:Ø 34.0 x 140.0 mm
Nominal Voltage: 450V AC
Nominal Current: 32 A
Cable Cross sections: 0.5 – 4.0 mm2
For cable diameters: 6.0 -17.0 mm
Temperature: T 125°C
IP Rate: IP68
Housing material: PA66 GF UL94 V0 / Polyamid PA6 V-2 (Cable glands)
Gasket: TPE
O-Rings: Silicone
Material characteristics: Halogenfreee
Errors and Technical changes reserved
Product specifications
| Pole | 5 |
| Nominal current | 32 A |
| Nominal voltage (V) | 450 V |
| Cable diameter | 6-17 mm |
| Wire section | 0.5-4.0 mm² |
| IP protection | IP68 |
| Certificates | CE, IEC |
| Manufacturer | Techno |
