About the product
- Modules with Samsung LM283B+ LED for backlighting contours, letters and characters in illuminated advertising / signage.
- Suitable for illuminated signs or light boxes with a depth of 3-15cm
- Available as 1, 2 and 3 modules
- High colour consistency, colour rendering and luminous efficacy
- Radiation characteristic: 170
- Integrated current control for very homogeneous illumination
- LED module with plastic housing (IP67 protection)
- Flexible chain, can be divided after each module (50 modules on one chain)
- 3M adhesive tape on the back
- Can also be fixed with screws
- Long service life
- 7-year warranty
Technical data
- Operating voltage: 12V
- Power: 1.44W
- Luminous flux: 170lm
- Colour temperature: 6500K
- Colour rendering: Ra>80
- Radiation pattern: 170
- Dimension: 77.8×15.4×10.4mm
- Number of LEDs per module: 3
- Number of modules in a chain: 50
- Max. Number of modules on a chain: 50
Product specifications
| Application | Single color |
| Operating mode | 12 V DC |
| Width | 15.4 mm |
| Colour temperature (K) | 6500 K |
| Colour rendering Ra | 80 |
| Height | 10.4 mm |
| IP protection | IP67 |
| Length | 77.8 mm |
| Shape | IP Module |
