About the product
2W medical DC/DC-Converter, Input 4.5…7V, Output +3.3V / +0.6A
Technical data
- 2Watt output power
- 8mm clearance & creepage distance
- 5000Vac IN/OUT isolation
- Less than 2μA leakage current
- No minimum load required
- Input voltage range: 4.5…7, 9.6…14.4, 12…18, 19.2…28.8Vdc
- Output voltage versions: 3.3, 5, 12, 15, ±5, ±12, ±15Vdc
- Short circuit output protection
- Operating altitude: 5000müM
- IEC60601-1, IEC62368-1 approved
- Warranty: 5 years
- Manufacturer: P-Duke
Product specifications
| Output voltage (VDC) | 3.3 V |
| Application | ITE/AV, Medical |
| Height | 12.5 mm |
| Width | 9.9 mm |
| Length | 19.6 mm |
| Package / case | SIP9 |
| Regulation | Regulated |
| I/O isolation | 5000 V AC |
| Input voltage ratio | N/A |
| Input voltage range (VDC) | 4.5-7 V |
| Nominal input voltage (VDC) | 5 V |
| Output current | 600 mA |
| Power | 2 W |
| Manufacturer | P-Duke |
Data sheets
