About the product
T-cable distributor TH390 from Techno, Italy
. 3-way cable distributor with wire protection*
- 3-way T-cable distributor
- For cable diameter: Ø 7.0 - 13.5 mm
- External dimensions: Ø 32.0 x 97.0 x 77.0 mm
- Protection classes: IP68
*Recommended for cable cross-sections < 1.0 mm2
Other Techno products and designs on request.
Technical data
Number of outlets: 3
External dimensions: Ø 32.0 x 97.0 x 77.0 mm
Nominal voltage: 450V AC
Nominal current: 24A
Cable cross-section: 0.25 - 1.5 mm2
For cable outer diameter: Ø 7.0 - 13.5 mm
Temperature range: T 125°C
Material:
.- Housing: PA66 GF UL94 V0
.- Cable connector: PA66 GF UL94 V0
.- Cable gland: PA66 UL94 V2
.- O-rings: Silicone
- Seals: TPE
Material properties: Halogen-free
Subject to errors and technical changes
Product specifications
| Manufacturer | Techno |
| Nominal voltage (V) | 450 V |
| Nominal current | 24 A |
| Number of poles | 3 |
| IP protection | IP68 |
| Connection cross-section (mm²) | 0.25 - 1.5 mm² |
| Cable diameter | 7-13.5 mm |
| Certificates | IEC, CE |
