About the product
3-way Y-cable connector/Y-power distributor THR399 from Techno, Italy
Labeling: L-N-E
- 3 Connections
- For cable diameter: Ø 6.0 - 13.5 mm
- Compact dimensions: Ø 32.0 x 65.5 x 135.0 mm
- Protection class: IP68
Other Techno products and designs on request.
Technical data
Number of connections: 3
Number of poles: 3
For cable diameter: Ø 6.0 - 13.50 mm
Connection cross-section: 0.50 - 1.50 mm2
Nominal voltage: 450 V AC
Nominal current: 32 A
External dimensions: Ø 32.0 x 65.5 x 135.0 mm
Protection class: IP68
Temperature: T 125°C
Housing material: PA66 GF UL94 V0 / PA66 UL94 V2 (cable gland)
O-rings: Silicone
Seals: TPE
Material properties: Halogen-free
Subject to errors and technical changes
Product specifications
| Manufacturer | Techno |
| Nominal voltage (V) | 450 V |
| Nominal current | 32 A |
| Connection cross-section (mm²) | 0.5 - 1.5 mm² |
| Number of poles | 3 |
| Product | Cable connector |
| Cable diameter | 6-13.5 mm |
