About the product
4-way cable connector/power distributor TH624 from Techno, Italy
.with 4 connections (1+3) - Simple and quick installation increases efficiency during installation.
Number of inputs/outputs: 4 (1+3)
. 1x socket
. 3x plug/pin
Locking: Screw
Matching plug connectors (single):
Sockets: THB.387.B5A / THB.387.B5A.L
Plug: THB.387.A5A / THB.387.A5A.L
Also available as a set with corresponding plug connectors: THH.624.A5A.L.R
Other Techno products and designs on request.
Technical data
Number of inputs/outputs: 4 (1+3)
External dimensions: 65.0 x 61.0 x 25.0 mm
Nominal voltage: 500V AC
Nominal current: 17.5 A AC/DC
Temperature range: -40°..+125°C
IP protection: IP66/IP68
Housing material: PA66 GF UL94 V0 / PA66 GF UL94 V2 (cable gland)
O-rings: TPE
Material properties: Halogen-free
Contacts: Brass
Subject to errors and technical changes
Product specifications
| Manufacturer | Techno |
| Nominal current | 17.5 A |
| Nominal voltage (V) | 500 V |
| Certificates | CE |
| IP protection | IP66 - IP68 |
| Number of poles | 5 |
