About the product
Mini Match PCB socket 8-pin, THT, straight from Don Connex
. Other unpublished products and designs from Don Connex on request.
Technical data
- Insulator material: PBT, glass reinforced, rated UL 94V-0
- Color: red
- Contact material: Phosphor bronze
- Rated current: 1A
- Contact resistance: 30 mΩ max.
- Insulation resistance: 3000 MΩ min.
- Dielectric strength: 500V AC for 1 minute
- Temperature range: -40˚C.. +105˚C
- Suitable connectors: A28, A28e, A28f & A28g series
Subject to errors and technical changes
Product specifications
| Nominal voltage (V) | 250 V |
| Contact grid | 2.54 mm |
