About the product
The WDR-60-48 DIN rail power supply unit is designed for operation with one or two phases. Thanks to the wide input range of 180 to 550Vac, the power supply unit is also particularly robust in unstable networks with high voltage peaks.
Technical data
- Suitable for mounting on TS-35/7.5/15 top-hat rails
- Operating temperature range from -30°C to +85°C
- LED display for DC OK
- Overvoltage category III
- Built-in DC OK relay contact
- Dimensions 32 x 125.2 x 102mm (W x H x D)
Product specifications
| Width | 32 mm |
| Overload behaviour | Constant current limiting |
| Input voltage range (VAC) | 180-550 V |
| Product series | WDR |
| Depth | 102 mm |
| Status signals | DC OK relay contact |
| Height | 125.2 mm |
| Output current | 1.25 A |
| Power | 60 W |
| Output voltage (VDC) | 48 V |
| Manufacturer | MEAN WELL |
| Certificates | EN61558-2-16, UL61010-1 |
