About the product
TDR-480-48 is a compact DIN rail power supply for 3-phase operation. The metal housing with a width of 85.5mm saves space in the control cabinet. With the high efficiency of 93%, the power loss is minimized to keep the heating in the control cabinet as low as possible. The power supply unit is ideal for industrial control systems, semiconductor production or automation applications.
Technical data
- 3 phase input voltage 340 to 550Vac (2 phase operation possible)
- Suitable for mounting on TS-35/7.5/15 top-hat rails
- High efficiency 93%
- Operating temperature range from -30°C to +70°C
- LED display for DC OK
- Dimensions 85.5 x 125.2 x 128.5mm (W x H x D)
Product specifications
| Manufacturer | MEAN WELL |
| Input voltage range (VAC) | 340-550 V |
| Overload behaviour | Constant current limiting |
| Width | 85.5 mm |
| Product series | TDR |
| Depth | 128.5 mm |
| Height | 125.2 mm |
| Power | 480 W |
| Output voltage (VDC) | 48 V |
| Output current | 10 mA |
| Certificates | IEC62368-1, UL62368-1, UL508 |
