10W DIN rail power supply 24V/0.42A

Delivery at your place between May 21 and Jun 25 2025

Add to cart

About the product

The compact MEAN WELL MDR-10-24 DIN rail power supply unit in a plastic housing saves space in the control cabinet. A DC-OK signal is integrated for remote monitoring.

Technical data

No load power consumption 0.75W
Suitable for mounting on TS-35/7.5/15 top-hat rails
LED display for DC OK
Dimensions 22.5 x 90 x 100mm (W x H x D)

Product specifications

Output voltage (VDC)	24 V
Overload behaviour	Hiccup mode
Output current	0.42 A
Width	22.5 mm
Product series	MDR
Depth	100 mm
Height	90 mm
Power	10 W
Input voltage range (VAC)	90-264 V
Manufacturer	MEAN WELL
Certificates	EN62368-1, AS/NZS62368-1, CNS15598-1, EAC TP TC 004, UL508
