EVO-Cam ICON video microscope with column stand and focus module

EVO Cam ICON increases the accuracy and efficiency of your inspection with impressive clarity and detail. The high-quality camera, sensor, customized lenses and advanced software features combine to deliver impressive image quality.

With an optical zoom range of 30:1 and a magnification of up to 725x, you can easily see all the details. The digital zoom extends this range even further, while full HD video, manual and automatic focusing ensure razor-sharp images at all times.

Configure 10 presets for faster transitions between tasks or operators. Easily integrate additional devices by sharing settings. Customize the system to your workspace and application with a comprehensive range of tripods, lenses and other accessories.

Technical data

• Full HD camera
• Illumination 8-point ring light. Color temperature 5,500K (adjustable with filter options)
• Transmitted light illumination Optional
• Control on/off, zoom in, zoom out, overview, illuminance of incident light,
• Illuminance of the transmitted light, image capture, menu
• Control panel Optional
• Interfaces HDMI, USB3 (PC connection), USB2 (independent image capture), WiFi (optional)
• Camera specifications
• Camera zoom 30:1
• Digital zoom 12:1
• Camera resolution 1920 x 1080
• Sensor 1/2.8" CMOS backlit
• Frame rate 50 fps & 60 fps (switchable)
• Saved file type PNG, JPEG+,JPEG,JPEG

Scope of delivery

• ECH007: Head, incident light, USB stick
• EVB021: Multi-axis column stand (without base plate)
• EVF111: Focus module with weight compensation (for EVB021)
