Item ID: 49015
1.65W DC/DC converter, input 4.75...32V, output 3...5.5V/500mA, SMD 10 pin
About the product
The R-78AAxx-0.5SMD series are non-isolated step-down converters with adjustable output that meet the requirements of RoHS 10/10 and the reflow soldering temperatures associated with vapor phase soldering. This makes these highly efficient switching regulators ideal for modern pick-and-place mass production. The efficiency of up to 97% means that very little energy is wasted as heat. The additional features such as remote on/off, continuous short circuit protection and adjustable output voltages will find many applications in the battery-powered appliance, industrial, medical and automotive markets.
Technical data
- Efficiency of up to 95%, no heat sinks required
- SMD housing for high reflow temperatures
- Buck converter with adjustable output voltage
- Large input range (4.74V - 32V)
- Short-circuit protection, thermal shutdown
- Remote-controlled switching on and off
Product specifications
| Height | 8.8 mm |
| Design | SMD10 |
| I/O isolation | not isolated |
| Output voltage (VDC) | 3.3-5 V |
| Length | 15.3 mm |
| Power | 1.65 W |
| Nominal input voltage (VDC) | 5-24 V |
| Width | 9.6 mm |
| Regulation | Regulated |
| Output current | 500 mA |
| Manufacturer | Recom |
| Output voltage range (VDC) | 3-5.5 V |
