About the product
The RPA60-FW series are 60 W DC/DC converters with high power density and a wide input voltage range in an industry standard 2 "x1" housing. Despite their small size, the RPA60-FW converters are fully specified devices with output currents up to 12 A, efficiency up to 93%, no minimum load, 1600 VDC isolation, tight regulation and low ripple/noise levels. The trimmable outputs are also fully protected against overtemperature, short circuit, overcurrent and overvoltage. The operating temperature range extends from -40°C to 46°C without derating. The converters are UL and EN50155 certified and are used in many railroad and industrial applications where board space is at a premium.
Technical data
- 4:1 Wide input voltage range
- 1.5kVDC insulation
- UL, IEC/EN60950-1 & EN50155 certified
- Efficiency of up to 93.3%
- OVP, OCP & OTP
- Operating temperature -40°C to +105°C with power reduction
Product specifications
| Output voltage (VDC) | 12 V |
| Design | 2×1 inch |
| Additional functions | Remote ON/OFF, Voltage Trim |
| I/O isolation | 1500 VDC |
| Height | 10.2 mm |
| Nominal input voltage (VDC) | 12-24 V |
| Output current | 5000 mA |
| Regulation | Regulated |
| Input voltage ratio | N/A |
| Length | 50.8 mm |
| Width | 25.4 mm |
| Manufacturer | Recom |
| Power | 60 W |
| Output voltage range (VDC) | 10.8-13.2 V |
