2W medical DC/DC converter, input 12...18V, output +3.3V / +0.6A

Delivery at your place between May 21 and Jun 25 2025

About the product

  • 2Watt output power
  • 8mm clearances & creepage distances
  • 5000Vac IN/OUT Isolation
  • Less than 2μA leakage current
  • No minimum load required
  • Input voltage range: 4.5..7, 9.6..14.4, 12..18, 19.2..28.8Vdc
  • Output voltage versions: 3.3, 5, 12, 15, ±5, ±12, ±15Vdc
  • Short-circuit output protection
  • Operating altitude: 5000m above sea level
  • IEC60601-1, IEC62368-1 approved
  • Warranty: 5 years
  • Manufacturer: P-Duke

Product specifications

Output current 600 mA
I/O isolation 5000 VAC
Height 12.5 mm
Width 9.9 mm
Length 19.6 mm
Nominal input voltage (VDC) 15 V
Manufacturer P-Duke
Regulation Regulated
Input voltage ratio N/A
Power 2 W
Output voltage (VDC) 3.3 V
Application ITE/AV, Medical
Design SIP9
