40W DC/DC converter, input 18..75V, output 15V/2.66A
Technical data
- Meets standard railroad approval EN50155
- 2x1 compact, flat 10.5mm housing
- 4:1 Wide entrance area
- Wide temperature range -40°.+90°C
- No minimum load required
- Fully encapsulated
- Protective circuits: permanent short circuit/overload/overvoltage/overtemperature/input undervoltage cut-off
- 1.6kVdc/3kVdc IN/OUT Isolation
- Remote ON/OFF control
- 3-year guarantee
- Manufacturer Mean Well
Product specifications
| Manufacturer | MEAN WELL |
| Application | Railroad, ITE/AV |
| I/O isolation | 3000 VDC |
| Additional functions | Remote ON/OFF, Voltage Trim |
| Output current | 2666 mA |
| Height | 10.5 mm |
| Nominal input voltage (VDC) | 24-72 V |
| Regulation | Regulated |
| Input voltage ratio | N/A |
| Length | 50.8 mm |
| Width | 25.4 mm |
| Output voltage (VDC) | 15 V |
| Power | 40 W |
| Design | 2×1 inch |
