About the product
75W DC/DC converter, input 9..75V, output 48V/1.56A
Technical data
- Efficiency 90%
- Fixed switching frequency
- Regulated outputs
- Remote ON/OFF
- Deeper No load power consumption
- Protective circuit: overcurrent/overvoltage/overtemperature/undervoltage cut-off
- 3000Vac I/O isolation
- Housing temperature -40°..+105°C
- Quarter brick according to industry standard 2.28 "x1.45 "x0.5"
- CB Test Certificate IEC62368-1
- UL62368-1 2nd, Reinforce Insulation
- EN50155 compliant with external components
- Shock & Vibration EN50155 (EN61373) compliant
- Fire & Smoke EN45545-2 compliant
- 5000m operating altitude
- 2-year guarantee
- Manufacturer Cincon
Product specifications
| Output voltage (VDC) | 48 V |
| Design | Quarterbrick |
| Additional functions | Parallel switchable, remote ON/OFF, remote sense, voltage trim |
| I/O isolation | 3000 VDC |
| Nominal input voltage (VDC) | 12-72 V |
| Output current | 1560 mA |
| Input voltage ratio | N/A |
| Length | 36.8 mm |
| Regulation | Regulated |
| Height | 12.7 mm |
| Width | 57.9 mm |
| Manufacturer | Cincon |
| Power | 75 W |
| Application | Railroad, ITE/AV |
