About the product
75W DC/DC converter, input 9..36V, output 15V/5A
Technical data
- 75Watt isolated output
- Efficiency 92.5%
- Deeper No load power consumption
- 2.05''x1.2×0.4'', 6-sided shielded metal housing
- 4:1 Input voltage ratio
- Regulated outputs
- Fixed switching frequency
- Protective circuits: Overcurrent/short circuit/input undervoltage
- Remote ON/OFF
- No tantalum capacitors available
- Complies with IEC/EN/UL62368-1 approval
- Full operating load at +54°C (including heat sink)
- 2-year guarantee
- Manufacturer Cincon
Product specifications
| Length | 52 mm |
| I/O isolation | 2250 VDC |
| Additional functions | Remote ON/OFF, Voltage Trim |
| Height | 10.2 mm |
| Nominal input voltage (VDC) | 12-24 V |
| Output current | 5000 mA |
| Regulation | Regulated |
| Input voltage ratio | N/A |
| Application | ITE/AV |
| Width | 30.5 mm |
| Manufacturer | Cincon |
| Output voltage (VDC) | 15 V |
| Power | 75 W |
| Design | 2.05×1.2 inch |
Data sheets
