About the product
8W DC/DC converter, input 18..36V, output +/-5V / +/-0.8A
Technical data
- SIP8 housing with international standard pinout
- 2:1 Input voltage range
- Operating temperature -40°..+90°C
- No minimum load required
- Efficiency 89%
- Protective circuit: permanent short circuit/overcurrent/input undervoltage
- 1.5kVdc I/O isolation
- Remote ON/OFF
- 9V output optionally available
- 3-year guarantee
- Manufacturer MEAN WELL
Product specifications
| Manufacturer | MEAN WELL |
| Additional functions | Remote ON/OFF |
| I/O isolation | 1500 VDC |
| Output current | 800 mA |
| Length | 21.8 mm |
| Height | 11.1 mm |
| Width | 9.2 mm |
| Output voltage (VDC) | 5 V |
| Nominal input voltage (VDC) | 24 V |
| Regulation | Regulated |
| Input voltage ratio | N/A |
| Application | ITE/AV |
| Power | 8 W |
| Design | SIP8 |
Data sheets
