About the product
10W DC/DC converter, input 9..36V, output +/-12V / +/-0.417A
Technical data
- 4:1 Input voltage ratio
- Regulated outputs
- 3000Vdc/2000Vac insulation
- 7..10Watt isolated outputs
- Efficiency 89.5%
- Deeper No load power consumption
- Compact SIP8 housing
- Fixed switching frequency
- Protective circuits: Short circuit/input undervoltage
- Remote ON/OFF
- No tantalum capacitors available
- 2-year guarantee
- Manufacturer Cincon
Product specifications
| Width | 9.5 mm |
| Design | SIP8 |
| Additional functions | Remote ON/OFF |
| Output current | 417 mA |
| Length | 22.9 mm |
| Height | 12 mm |
| Nominal input voltage (VDC) | 12-24 V |
| Regulation | Regulated |
| Input voltage ratio | N/A |
| Output voltage (VDC) | 12 V |
| Application | ITE/AV |
| Power | 10 W |
| Manufacturer | Cincon |
| I/O isolation | 3000 VDC |
Data sheets
