About the product
15W medical DC/DC converter, input 9..18V, output 15V/1A
Technical data
- DIP 2''x1'' housing with international standard pinout
- 2:1 wide input voltage range
- Low leakage current 5microAmp
- Wide input temperature range -40°.+90°C
- Medical approval (2xMOPP) according to IEC60601-1
- No minimum load required
- Protective circuit: permanent short circuit/overload/input undervoltage
- 4000Vac IN/OUT insulation (reinforced insulation)
- 3-year guarantee
- Manufacturer Mean Well
Product specifications
| Manufacturer | MEAN WELL |
| Design | 2×1 inch |
| Height | 12 mm |
| Nominal input voltage (VDC) | 12-15 V |
| Regulation | Regulated |
| Input voltage ratio | N/A |
| Length | 50.8 mm |
| Width | 25.4 mm |
| Application | ITE/AV, Medical |
| Power | 15 W |
| Output current | 1000 mA |
| Output voltage (VDC) | 15 V |
| I/O isolation | 4000 VDC |
Data sheets
