About the product
2.3W DC/DC converter, input 9..36V, output 3.3V/0.7A
Technical data
- 4:1 Input voltage range
- 1600Vdc insulation
- Efficiency 84%
- Temperature range -40° to +80°C
- Protective circuit: Short circuit
- Remote On/Off control (CTRL)
- Undervoltage blocking circuit
- 3-year guarantee
- Manufacturer Motien
Product specifications
| Length | 14 mm |
| I/O isolation | 1600 VDC |
| Additional functions | Remote ON/OFF |
| Manufacturer | Motes |
| Height | 8.1 mm |
| Width | 14.8 mm |
| Power | 2.3 W |
| Nominal input voltage (VDC) | 12-24 V |
| Regulation | Regulated |
| Input voltage ratio | N/A |
| Output voltage (VDC) | 3.3 V |
| Application | ITE/AV |
| Output current | 700 mA |
| Design | DIP8 |
