About the product
1W DC/DC converter, input 45.6..52.8V, output 15V/0.067A
Technical data
- SIP6 housing with industry standard pinout
- Operating temperature -40°..+90°C
- Complies with EN55032 radiated class B without additional components
- Protective circuit: Short circuit
- 1500kVdc I/O isolation
- Low cost
- 3-year guarantee
- Manufacturer Mean Well
Product specifications
Manufacturer | MEAN WELL |
I/O isolation | 1500 VDC |
Height | 10.14 mm |
Length | 19.6 mm |
Width | 7.1 mm |
Output current | 67000 mA |
Nominal input voltage (VDC) | 48 V |
Regulation | Regulated |
Input voltage ratio | +/-10 % |
Power | 1 W |
Application | ITE/AV |
Output voltage (VDC) | 15 V |
Design | SIP6 |
