About the product
1W DC/DC converter, input 22.8..26.4V, output +/-12V / +/-0.042A
Technical data
- SIP7 housing with industry standard pinout
- Operating temperature range -40°..+105°C
- Complies with EN55032 radiated class B without additional components
- Efficiency 87%
- Protective circuit: short circuit/overcurrent
- 3kVdc I/O isolation
- Low cost
- 3-year guarantee
- Manufacturer Mean Well
Product specifications
| Manufacturer | MEAN WELL |
| Additional functions | Remote ON/OFF |
| I/O isolation | 1500 VDC |
| Height | 10.14 mm |
| Length | 19.6 mm |
| Width | 7.1 mm |
| Output current | 42000 mA |
| Nominal input voltage (VDC) | 24 V |
| Regulation | Regulated |
| Input voltage ratio | +/-10 % |
| Output voltage (VDC) | 12 V |
| Power | 1 W |
| Application | ITE/AV |
| Design | SIP6 |
Data sheets
