600W DC/DC converter, input 43...160V, output 24V/25A

The CFB600W-110S series is an industry standard DC-DC converter with up to 600 W output power. It has a wide input voltage range from 43 to 160VDC (110VDC nominal) with 2250Vdc isolation.

Thanks to the high efficiency of up to 88%, operation in the
temperature range from -40°C to 100°C is possible. A very low power consumption in idle mode (25mA) makes the converter the ideal solution for energy-critical system applications.

Technical data

• 600W isolated outputs
• Efficiency up to 88%
• Regulated outputs
• Protective circuit: overtemperature/overvoltage/overcurrent/permanent short circuit
• Isolated remote on/off control
• Full Brick industry standard
• UL60950-1 2nd (Basic Insulation)
• Complies with EN50155 with external components
• Shock & Vibration complies with EN50155(EN61373) and Fire & Smoke complies with EN45545-2
• 2-year guarantee
• Manufacturer Cincon
