About the product
15W DC/DC converter, input 18..36V, output +/-15V / +/-0.5A
Technical data
- 15W isolated outputs
- Efficiency 90%
- 2:1 Entrance area
- Regulated outputs
- Protective circuit: Input undervoltage/overcurrent/short circuit
- Remote On/Off
- Safety standard UL60950-1, EN60950-1 and IEC60950-1
- Dimensions 25.4 x 25.4 x 10.2mm (L x W x H)
- 2-year guarantee
- Manufacturer Cincon
Option: Suffix "S" = SMD housing / 25.4 x 25.4 x 10.2mm (L x W x H)
Product specifications
| Output current | 500 mA |
| Additional functions | Remote ON/OFF, Voltage Trim |
| I/O isolation | 1500 VDC |
| Height | 11.7 mm |
| Nominal input voltage (VDC) | 24 V |
| Regulation | Regulated |
| Input voltage ratio | N/A |
| Length | 25.4 mm |
| Output voltage (VDC) | 15 V |
| Width | 25.4 mm |
| Application | ITE/AV |
| Power | 15 W |
| Manufacturer | Cincon |
| Design | 1×1 inch |
Data sheets
