About the product
30W DC/DC converter, input 9..36V, output +/-12V / +/-1.25A
Technical data
- Wide entrance area 4 :1
- Insulation voltage 1600Vdc
- No minimum load required
- Efficiency 92%
- Extended temperature range -40°C to +100°C
- Adjustable output voltage
- Remote On/Off Control (Ctrl)
- Short-circuit proof
- Overcurrent protection
- Overvoltage protection
- Overtemperature protection
- 3-year guarantee
- Manufacturer Motien
Product specifications
| Height | 10.4 mm |
| Design | 1×1 inch |
| Manufacturer | Motes |
| Additional functions | Remote ON/OFF, Voltage Trim |
| Output current | 1250 mA |
| Nominal input voltage (VDC) | 12-24 V |
| Regulation | Regulated |
| Input voltage ratio | N/A |
| Length | 25.4 mm |
| Output voltage (VDC) | 12 V |
| Width | 25.4 mm |
| Application | ITE/AV |
| Power | 30 W |
| I/O isolation | 1600 VDC |
