About the product
2W DC/DC converter, input 4.5..5V, output +/-15V / +/-0.667A
Technical data
- 7 pin SIL housing
- High insulation voltage 5200Vdc
- Deep ripple & noise
- Efficiency 85%
- Short-circuit proof
- Temperature range -40°C to +90°C
- Deep coupling capacity
- Particularly suitable for IGBT applications
- 3-year guarantee
- Manufacturer Motien
Product specifications
| Application | ITE/AV |
| Design | SIP7 |
| Manufacturer | Motes |
| Width | 7.2 mm |
| Output current | 67000 mA |
| Height | 10 mm |
| Length | 19.5 mm |
| Regulation | Unregulated |
| Input voltage ratio | +/-10 % |
| Nominal input voltage (VDC) | 5 V |
| Output voltage (VDC) | 15 V |
| Power | 2 W |
| I/O isolation | 5200 VDC |
