About the product
3W DC/DC converter, input 18..36V, output 15V/0.2A
Technical data
- DIP24 housing with industrial pinout
- Input voltage range 2:1
- Temperature range -40°C to +90°C
- No minimum load required
- Complies with EN55032 class A without external components
- Efficiency 87%
- Protective circuit: short circuit / overcurrent / undervoltage
- Insulation voltage 3kVdc
- 3-year guarantee
- Manufacturer Mean Well
Product specifications
| Manufacturer | MEAN WELL |
| Design | DIP24 |
| Height | 10.2 mm |
| Width | 20.3 mm |
| Length | 31.8 mm |
| Output current | 200000 mA |
| Nominal input voltage (VDC) | 24 V |
| Regulation | Regulated |
| Input voltage ratio | N/A |
| Application | ITE/AV |
| Power | 3 W |
| Output voltage (VDC) | 15 V |
| I/O isolation | 3000 VDC |
