About the product
1W DC/DC converter, input 10.8..13.2V, output 15V/0.67A
Technical data
- SMD housing with industrial pinout
- Temperature range -40°C to +90°C
- Complies with EN55032 class B without external components
- Efficiency 84%
- Short-circuit proof
- Insulation voltage 1.5kVdc
- Low cost
- 3-year guarantee
- Manufacturer Mean Well
Product specifications
| Manufacturer | MEAN WELL |
| I/O isolation | 1500 VDC |
| Height | 7.1 mm |
| Width | 10.9 mm |
| Length | 12.9 mm |
| Output current | 67000 mA |
| Nominal input voltage (VDC) | 12 V |
| Regulation | Unregulated |
| Input voltage ratio | +/-10 % |
| Power | 1 W |
| Application | ITE/AV |
| Output voltage (VDC) | 15 V |
| Design | SMD8 |
