About the product
8W DC/DC converter, input 13..70V, output 5V/1.6A
Technical data
- Wide input voltage range
- Efficiency 86%
- Insulation voltage 3000Vdc
- Short-circuit proof
- Undervoltage limitation
- Overcurrent protection
- Overvoltage protection
- Temperature range -40°C to +85°C
- Remote On/Off control
- Railroad approval EN50155
- 3-year guarantee
- Manufacturer Motien
Product specifications
| Power | 8 W |
| Application | Railroad, ITE/AV |
| I/O isolation | 3000 VDC |
| Manufacturer | Motes |
| Additional functions | Remote ON/OFF, Voltage Trim |
| Input voltage ratio | N/A |
| Nominal input voltage (VDC) | 15-48 V |
| Height | 16.4 mm |
| Length | 27.6 mm |
| Output current | 1600 mA |
| Regulation | Regulated |
| Width | 27.6 mm |
| Output voltage (VDC) | 5 V |
| Design | 1.09×1.09 inch |
Data sheets
