About the product
10W DC/DC converter, input 9.8..36V, output +/-5V / +/-1A
Technical data
- Wide input voltage range 4:1
- Protection circuit : short circuit / overcurrent / overvoltage
- Insulation voltage 1kVdc
- Built-in EMI filter
- No additional cooling required
- Remote On/Off Control
- Low cost
- High reliability
- 2-year guarantee
- Manufacturer Mean Well
Product specifications
| Manufacturer | MEAN WELL |
| I/O isolation | 1000 VDC |
| Design | Open frame |
| Nominal input voltage (VDC) | 12-24 V |
| Output voltage (VDC) | 5 V |
| Regulation | Regulated |
| Input voltage ratio | N/A |
| Height | 10 mm |
| Length | 50.8 mm |
| Width | 25.4 mm |
| Application | ITE/AV |
| Power | 10 W |
| Output current | 1000 mA |
| Additional functions | Remote ON/OFF |
Data sheets
