About the product
14.8W DC/DC converter, input 18..75V, output 3.3V/4.5A
Technical data
- 20W isolated outputs
- Shielded metal housing
- Efficiency 89%
- Low no-load current consumption
- 4:1 Entrance area
- Regulated outputs
- Protective circuit: Input undervoltage/overcurrent/short circuit
- Remote On/Off
- Safety standard UL60950-1, EN60950-1 and IEC60950-1
- Dimensions 25.4 x 25.4 x 10.2mm (L x W x H)
- 2-year guarantee
- Manufacturer Cincon
Product specifications
| Manufacturer | Cincon |
| Additional functions | Remote ON/OFF, Voltage Trim |
| I/O isolation | 1500 VDC |
| Output current | 4500 mA |
| Height | 11.7 mm |
| Nominal input voltage (VDC) | 24-72 V |
| Regulation | Regulated |
| Input voltage ratio | N/A |
| Length | 25.4 mm |
| Width | 25.4 mm |
| Output voltage (VDC) | 3.3 V |
| Application | ITE/AV |
| Power | 15 W |
| Design | 1×1 inch |
