75W DC/DC converter, input 9..36V, output 15V/5A
Technical data
- 75W isolated outputs
- Efficiency 87%
- Quarter brick housing
- 4:1 Entrance area
- Regulated outputs
- Protective circuit: overvoltage/short circuit
- Safety standard UL60950-1, EN60950-1 and IEC60950-1
- Dimensions 36.8 x 57.9 x 12.7mm (L x W x H)
- 2-year guarantee
- Manufacturer Cincon
Product specifications
| Power | 75 W |
| Design | Quarterbrick |
| I/O isolation | 1500 VDC |
| Length | 36.8 mm |
| Nominal input voltage (VDC) | 12-24 V |
| Output current | 5000 mA |
| Regulation | Regulated |
| Input voltage ratio | N/A |
| Height | 12.7 mm |
| Width | 57.9 mm |
| Application | ITE/AV |
| Manufacturer | Cincon |
| Output voltage (VDC) | 15 V |
| Additional functions | Remote ON/OFF, Remote sense, Voltage Trim |
