60W DC/DC converter, input 43..160V, output 48V/1.25A
Technical data
- 60W isolated outputs
- Efficiency 92%
- Industrial standard Quarter Brick Package
- Low no-load current consumption
- 4:1 Entrance area
- Regulated outputs
- Remote On/Off
- Protective circuit: overtemperature/overvoltage/overcurrent
- Safety standard UL60950-1 (Basic Insulation)
- Shock & vibration complies with standard EN50155 (EN61373)
- Designed for operations up to 4000m.a.s.l. operating altitude
- Dimensions 57.9 x 36.8 x 12.7mm (L x W x H)
- 2-year guarantee
- Manufacturer Cincon
Product specifications
| Output voltage (VDC) | 48 V |
| Application | Railroad, ITE/AV |
| Design | Quarterbrick |
| I/O isolation | 3000 VDC |
| Length | 36.8 mm |
| Nominal input voltage (VDC) | 48-110 V |
| Output current | 1250 mA |
| Regulation | Regulated |
| Input voltage ratio | N/A |
| Height | 12.7 mm |
| Width | 57.9 mm |
| Manufacturer | Cincon |
| Power | 60 W |
| Additional functions | Remote ON/OFF, Remote sense, Voltage Trim |
