About the product
150W DC/DC converter, input 18..75V, output 28V/5.4A
Technical data
- 150W isolated outputs
- Efficiency 92%
- Quarter Brick Package
- 4:1 Entrance area
- Regulated outputs
- Remote On/Off
- Low no-load current consumption
- Protective circuit: overtemperature/overvoltage/overcurrent/short circuit
- Safety standard UL60950-1, EN60950-1 and IEC60950-1
- Shock vibration according to MIL-STD-810F / EN61373
- Dimensions 57.9 x 36.8 x 12.7mm (L x W x H)
- 2-year guarantee
- Manufacturer Cincon
Product specifications
| Power | 150 W |
| Design | Quarterbrick |
| Additional functions | Parallel switchable, remote ON/OFF, remote sense, voltage trim |
| Output current | 5400 mA |
| Nominal input voltage (VDC) | 24-72 V |
| Length | 36.8 mm |
| Regulation | Regulated |
| Input voltage ratio | N/A |
| Height | 12.7 mm |
| Width | 57.9 mm |
| Output voltage (VDC) | 28 V |
| Application | ITE/AV |
| Manufacturer | Cincon |
| I/O isolation | 2250 VDC |
Data sheets
