About the product
99W DC/DC converter, input 9..36V, output 3.3V/30A
Technical data
- 100W isolated outputs
- 4:1 Entrance area
- Quarter Brick Package
- Efficiency 88%
- Regulated outputs
- Protective circuit: Input undervoltage/overvoltage/overcurrent/overtemperature
- Remote ON/OFF
- Safety standard UL60950-1
- Dimensions 36.8 x 57.9 x 12.7mm (L x W x H)
- 2-year guarantee
- Manufacturer Cincon
Product specifications
| Power | 100 W |
| Application | Railroad, ITE/AV |
| Design | Quarterbrick |
| I/O isolation | 1500 VDC |
| Length | 36.8 mm |
| Output current | 30000 mA |
| Nominal input voltage (VDC) | 12-24 V |
| Regulation | Regulated |
| Input voltage ratio | N/A |
| Height | 12.7 mm |
| Width | 57.9 mm |
| Output voltage (VDC) | 3.3 V |
| Manufacturer | Cincon |
| Additional functions | Remote ON/OFF, Remote sense, Voltage Trim |
