About the product
The CFB600-300S series is an industry standard DC-DC converter with up to 600 W output power. It has a high input voltage range of 180 to 425VDC (300VDC nominal) with 3000VAC isolation.
Thanks to the high efficiency of up to 91%, operation in the temperature range from -40°C to 100°C is possible. A very low power consumption in idle mode (10mA) makes the converter the ideal solution for energy-critical system applications.
Technical data
- 600W isolated outputs
- Efficiency 92%
- Industry Full Brick Package
- Protective circuit: Input undervoltage/overcurrent/overvoltage/overtemperature
- Remote ON/OFF
- Safety standard UL60950-1
- Dimensions 116.8 x 61.0 x 12.7mm (L x W x H)
- 2-year guarantee
- Manufacturer Cincon
Product specifications
| Output voltage (VDC) | 12 V |
| Additional functions | 10VDC auxiliary output, parallel switchable, remote ON/OFF, voltage trim |
| I/O isolation | 3000 VDC |
| Output current | 50000 mA |
| Regulation | Regulated |
| Input voltage ratio | N/A |
| Nominal input voltage (VDC) | 300 V |
| Height | 12.7 mm |
| Length | 116.8 mm |
| Application | ITE/AV |
| Manufacturer | Cincon |
| Power | 600 W |
| Width | 61 mm |
| Design | Fullbrick |
