About the product
40W DC/DC converter, input 18..75V, output +/-15V / +/-1.333A
Technical data
- 40W isolated outputs
- Efficiency 91%
- 6-sided, shielded metal housing
- 4:1 Entrance area
- Regulated outputs
- Low no-load current consumption
- Protective circuit: Input undervoltage/overcurrent/short circuit
- Remote On/Off
- Safety standard UL60950-1, EN60950-1 and IEC60950-1
- Dimensions 52 x 30.5 x 10.2mm (L x W x H)
- 2-year guarantee
- Manufacturer Cincon
Product specifications
| Length | 52 mm |
| Application | Railroad, ITE/AV |
| I/O isolation | 3000 VDC |
| Additional functions | Remote ON/OFF, Voltage Trim |
| Output current | 1333 mA |
| Nominal input voltage (VDC) | 24-72 V |
| Height | 10.2 mm |
| Regulation | Regulated |
| Input voltage ratio | N/A |
| Output voltage (VDC) | 15 V |
| Width | 30.5 mm |
| Manufacturer | Cincon |
| Power | 40 W |
| Design | 2.05×1.2 inch |
