About the product
The CFB400W series is an isolated DC-DC converter with up to 80A output current. The converter delivers a precisely regulated output voltage and covers an input voltage range of 9 to 36Vdc or 18 to 75Vdc. These modules achieve a high efficiency of up to 90%, resulting in very good thermal characteristics.
Standard functions include an isolated remote ON/OFF (positive or negative), remote sense, output voltage regulation and integrated protection circuits for overvoltage, overload and overtemperature.
Technical data
- 400W isolated outputs
- Efficiency 90%
- Industry standard Full Brick
- Protective circuit: Input undervoltage/overtemperature/overvoltage/overcurrent
- Remote On/Off
- Safety standard UL60950-1
- Dimensions 116.8 x 61.0 x 12.7mm (L x W x H)
- 2-year guarantee
- Manufacturer Cincon
Product specifications
| Output voltage (VDC) | 24 V |
| Additional functions | 10VDC auxiliary output, parallel switchable, remote ON/OFF, voltage trim |
| I/O isolation | 1500 VDC |
| Output current | 16700 mA |
| Nominal input voltage (VDC) | 12-24 V |
| Regulation | Regulated |
| Input voltage ratio | N/A |
| Height | 12.7 mm |
| Length | 116.8 mm |
| Application | ITE/AV |
| Power | 400 W |
| Manufacturer | Cincon |
| Width | 61 mm |
| Design | Fullbrick |
Data sheets
