About the product
2W DC/DC converter, input 12V, output +/-12V / +/-0.083A
Technical data
- 7 pin SIL
- 1000Vdc insulation
- Small ripple and noise
- Efficiency up to 86
- Operating temperature range -40°C to +85°C
- Black plastic housing non-conductive
- 7 Pin SIL Dimension 19.5 x 6 x 10mm (L x W x H)
- 14 Pin DIL Dimension 20.32 x 10.16 x 6.88mm (L x W x H)
- 3-year guarantee
- Manufacturer Motien
Option: Suffix "H6" = 6000Vdc insulation
Product specifications
| Application | ITE/AV |
| Manufacturer | Motes |
| I/O isolation | 1000 VDC |
| Nominal input voltage (VDC) | 12 V |
| Output current | 83000 mA |
| Height | 10 mm |
| Width | 6 mm |
| Length | 19.5 mm |
| Regulation | Unregulated |
| Input voltage ratio | +/-10 % |
| Output voltage (VDC) | 12 V |
| Power | 2 W |
| Design | SIP7 |
