About the product
3W DC/DC converter, input 18..75V, output +/-24V / +/-0.63A
Technical data
- 24 pin DIP housing, SMD switching technology
- Next 4:1 Entrance area
- 1500Vdc insulation
- Permanently short-circuit proof
- Efficiency up to 81
- Operating temperature range -40°C to +85°C
- EMC filter complies with EN55032 Class A without external components
- Black plastic housing non-conductive
- Dimension 31.75 x 20.32 x 10.16mm (L x W x H)
- 3-year guarantee
- Manufacturer Motien
Option: Suffix "H" = 3000Vdc insulation
Product specifications
| Power | 3 W |
| Design | DIP24 |
| I/O isolation | 1500 VDC |
| Output current | 63000 mA |
| Output voltage (VDC) | 24 V |
| Nominal input voltage (VDC) | 24-72 V |
| Height | 10.16 mm |
| Width | 20.32 mm |
| Length | 31.75 mm |
| Regulation | Regulated |
| Input voltage ratio | N/A |
| Application | ITE/AV |
| Manufacturer | Motes |
