About the product
1W DC/DC converter, input 9..18V, output 12V/0.083A
Technical data
- 6 pin SIL, SMD switching technology
- 2:1 Entrance area
- 1500Vdc insulation
- Regulated output
- No minimum load required
- Permanently short-circuit proof
- Efficiency up to 81
- Small ripple and noise
- Operating temperature range from -40°C to +85°C
- Dimensions 17 x 7.62 x 11mm (L x W x H)
- 3-year guarantee
- Manufacturer Motien
Product specifications
| Output voltage (VDC) | 12 V |
| Manufacturer | Motes |
| I/O isolation | 1500 VDC |
| Height | 7.62 mm |
| Output current | 84000 mA |
| Width | 10.5 mm |
| Length | 17 mm |
| Nominal input voltage (VDC) | 12-15 V |
| Regulation | Regulated |
| Input voltage ratio | N/A |
| Power | 1 W |
| Application | ITE/AV |
| Design | SIP6 |
Data sheets
