About the product
6W DC/DC converter, input 18..72V, output 12V/0.5A
Technical data
- 24 DIP housing
- Next 4:1 Entrance area
- 1500Vdc insulation
- Permanently short-circuit proof
- Metal housing standard
- Efficiency up to 84%
- Operating temperature range -40°C to +85°C
- Dimension 31.75 x 20.32 x 10.16mm (L x W x H)
- EMI complies with EN55022 Class A
- 3-year guarantee
- Manufacturer Motien
Product specifications
| Output voltage (VDC) | 12 V |
| Design | DIP24 |
| I/O isolation | 1500 VDC |
| Height | 10.16 mm |
| Width | 20.32 mm |
| Length | 31.75 mm |
| Nominal input voltage (VDC) | 24-48 V |
| Regulation | Regulated |
| Input voltage ratio | N/A |
| Application | ITE/AV |
| Power | 6 W |
| Output current | 500 mA |
| Manufacturer | Motes |
