About the product
2W DC/DC converter, input 5V, output 15V/0.133A
Technical data
- 4 pin SIL housing
- 1000Vdc insulation
- Small ripple and noise
- Efficiency up to 88%
- Operating temperature range -40°C to +85°C
- Black plastic housing non-conductive
- EMI complies with EN55022 Class B
- Dimension 11.68 x 7.5 x 10.15mm (L x W x H)
- 3-year guarantee
- Manufacturer Motien
Product specifications
| Width | 7.5 mm |
| Manufacturer | Motes |
| I/O isolation | 1000 VDC |
| Output current | 134000 mA |
| Height | 10.15 mm |
| Length | 11.68 mm |
| Regulation | Unregulated |
| Input voltage ratio | +/-10 % |
| Nominal input voltage (VDC) | 5 V |
| Power | 2 W |
| Application | ITE/AV |
| Output voltage (VDC) | 15 V |
| Design | SIP4 |
