About the product
2W DC/DC converter, input 3.3V, output +/-7.2V / +/-0.138A
Technical data
- 7 pin SIL
- 1000Vdc insulation
- Small ripple and noise
- Efficiency up to 86
- Operating temperature range -40°C to +85°C
- Black plastic housing non-conductive
- 7 Pin SIL Dimension 19.5 x 6 x 10mm (L x W x H)
- 14 Pin DIL Dimension 20.32 x 10.16 x 6.88mm (L x W x H)
- 3-year guarantee
- Manufacturer Motien
Option: Suffix "H6" = 6000Vdc insulation
Product specifications
| Application | ITE/AV |
| Design | DIP24 |
| I/O isolation | 1000 VDC |
| Output voltage (VDC) | 7.2 V |
| Output current | 138000 mA |
| Height | 6.88 mm |
| Width | 10.16 mm |
| Length | 20.32 mm |
| Nominal input voltage (VDC) | 3.3 V |
| Regulation | Unregulated |
| Input voltage ratio | +/-10 % |
| Power | 2 W |
| Manufacturer | Motes |
Data sheets
