About the product
20W DC/DC converter, input 18..36V, output 5V/4A
Technical data
- DIP24 housing with industrial pin-out
- 2:1 wide input voltage range
- -40°C to + 85°C Temperature range
- No minimum load required
- Compliant with EN55032 radiated Class A without additional components
- Efficiency 89%
- Protective circuits: Permanent short circuit/overcurrent
- 1.5KVdc I/O isolation
- Remote On/Off Control
- 3-year guarantee
- Manufacturer MEAN WELL
Product specifications
| Manufacturer | MEAN WELL |
| Design | DIP24 |
| I/O isolation | 1500 VDC |
| Output current | 4000 mA |
| Height | 10.2 mm |
| Width | 20.3 mm |
| Length | 31.8 mm |
| Nominal input voltage (VDC) | 24 V |
| Regulation | Regulated |
| Input voltage ratio | N/A |
| Application | ITE/AV |
| Output voltage (VDC) | 5 V |
| Power | 20 W |
| Additional functions | Remote ON/OFF |
